Name: Automatic Twin-Screw Brick Cutter Machine 3 kW 1200kg
Brand: Xi'an Brictec Engineering Co., Ltd.
SKU: QPJ-I
Price: 28,000.00 USD
Availability: InStock

Rincian produk

Tempat asal: CINA

Nama merek: Brictec

Nomor model: QPJ-I

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1

Harga: USD24000-32000$

Waktu pengiriman: 20-30 hari kerja

Syarat-syarat pembayaran: L/C, D/A, D/P, T/T, Western Union, Moneygram

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                automatic twin-screw brick cutter, 3 kW brick cutting machine, 1200kg brick cutter machine


Otomatis:	Ya	Jenis:	mesin pembuat batu bata tanah liat
Sudut pemotongan yang bisa disesuaikan:	Ya	Kekuatan:	3 kW
Jenis produk:	Mesin pemotong	Berat:	1200kg
Kondisi:	Baru	Metode:	Pemotong
Pengolahan:	Mesin Pemotong Batu Bata	Penggunaan:	Memotong batu bata untuk proyek konstruksi

Otomatis:	Ya
Jenis:	mesin pembuat batu bata tanah liat
Sudut pemotongan yang bisa disesuaikan:	Ya
Kekuatan:	3 kW
Jenis produk:	Mesin pemotong
Berat:	1200kg
Kondisi:	Baru
Metode:	Pemotong
Pengolahan:	Mesin Pemotong Batu Bata
Penggunaan:	Memotong batu bata untuk proyek konstruksi

Automatic Twin-Screw Brick Cutter Machine 3 kW 1200kg

Brick Cutter Twin-Screw Frame Wire-Cutting Machine for Clay Brick Cutting Fully Automatic

Equipment Introduction

The twin-screw frame wire-cutter is a wire-cutting device driven by two synchronized ball screws, moving the cutting frame vertically to slice wet clay, shale or coal-gangue bricks to exact length.

Application in Clay Brick Plant

Positioned downstream of the extruder, it converts the continuous clay column into uniform brick blanks before stacking, drying and firing.

Function

The high-rigidity twin-screw drive ensures all cutting wires move simultaneously at identical speed and position, giving synchronous, distortion-free cuts.

Comparison with Synchronous Cutter

Item	Twin-Screw Frame	Synchronous Cutter
Drive	Mechanical twin screws	Servo motor + linkage
Wire qty	Up to 20 wires, single break replaceable	Usually fixed set
Wire-break protection	Single break continues running	Requires full stop
Maintenance	Modular quick change	Complex linkage adjustment

Cutting Advantages

If one wire breaks, the rest keep working--non-stop production
Cutting accuracy ≤ ±1 mm with clean edges
Modular frame allows full wire set change in 10 min
Wear-resistant screws last ≥30,000 h maintenance-free

Key Specifications

Max cutting width: 1,200 mm
Cutting frequency: 15-45 cuts/min (VFD adjustable)
Installed power: 11 kW
Brick types: solid, perforated, hollow and pavers
